The TD120 utilizes all day blind technology, high sensitivity, strong anti-interference ability, and is not affected by sunlight.
It features uv dual-field optical zoom, capable of full-field detection at both near and far distances. Compact and ergonomic in design, it offers simple operation and easy navigation with an intelligent menu. When combined with professional analysis and reporting software, it provides effective assistance for preventive testing in substations and high-voltage transmission and distribution lines.
UV sensitivity reached 2.0×10-18watt/cm2
Supports UV dual FOV, 2x optical zoom
Accurate overlay of UV and visible light, auto synchronize focusing
Noise interference is small, using solar-blind detector
Unique UV enhancement mode, detecting small discharges
Ergonomic design, intelligent menu
Equipped with environmental sensors, 500m laser ranging
High integration, low power consumption, single battery usage for 4 hours
Professional report analysis software, more conducive to discharge analysis
Item | TD120 |
UV-Optical properties | |
Minimum UV sensitivity | 2.0 x10-18 watt/cm2 |
Minimum discharge detection | 1.0pC @15m |
Spectral range | 240-280nm |
FOV | 11.2°x8.4°/5.6°x4.2° Dual FOV |
Photon counting | Support |
Amplification | 2X(optical), 4X, 8X |
Visible light optical properties | |
Minimum visible light sensitivity | 0.01LuX |
IR resolution | 1920x1080 |
Amplification | 18X optical zoom, 16X digital zoom |
Image Performance | |
LCD | 5.5” AMOLED LCD screen |
UV enhancement mode | Support |
Interface | |
Video output | HDMI |
Laser Ranging | 500 meters, can be synchronized |
Proximity sensor | auto screen off |
Temperature and humidity sensors | Yes, auto synchronization |
Type-C | Data transmission |
BLUETOOTH/ WIFI/ GPS | Yes |
4G | Support extension (domestic version) |
Tripod mount | 1/4”-20 |
Power System | |
External power | DC:9V-12V |
Battery type | Lithium batteries (rechargeable) |
Battery operating time | 4h continuous (room temperature) |
Environment Parameters | |
Operating temperature range | -20℃-+55℃ |
Storage temperature range | -30℃~+60℃ |
Humidity | 90%(non-condensing) |
Protection level | IP54 |
Physical data | |
Size | 305mmx169mmx160mm |
Weight | 2.5kg |
Packing | |
Standard | Corona camera, battery, charger, SD card, SD card reader, video cable, USB cable, adapter, USB drive, safety box, headphone manual, warranty card, certificate |
Optional | Tripod |
Quality assurance | |
Report | Meets type testing |
Power industry
Electrified railway
Research institutions
